Name: Overhead Mount Reed Switch 1L-MSO-102L 1 LEAP Operating Gap 1/2″ (12 mm) min
Brand: 1 LEAP Technologies
SKU: 1-MSO-102L NO
Price: 650 INR
Availability: InStock
Rating: 5 (1 reviews)

Overhead Mount Reed Switch 1L-MSO-102L 1 LEAP Operating Gap 1/2″ (12 mm) min

Piece (+18% GST extra)

Overhead Mount Magnetic Reed Switch 1L-MSO-102L
Operating gap 1/2″ (12 mm) min

Weight

0.3 kg

Dimensions

13 × 9 × 4.5 cm

1-MSO-102L

Contact Rating : 10W/VA
Switching Voltage (Max.) : 200 VDC
Switching Current (Max.) : 0.5 Amp.
Contact Resistance (Min.) : 150 milli ohms
Life Expectancy : 10 x 10⁶ Operations
Insulation Resistance : 10 9 ohms
Shock Resistance : 30G for 11 mSec.
Vibration Resistance : 20G ( 10 to 1000Hz)
Plastic Material : ABS Plastic (Unless otherwise specified)

*Custom Wire Size Available On Request

5000 in stock (can be backordered)

For Bulk Orders Contact Us :- 9220433260

✨ Special Offers for You!

🎯 First Purchase Offer! — Get ₹200 OFF on orders above ₹1,000. Use Code FIRSTORDER200
🏷️ Use Code 1LEAP05 → Get 5% OFF
🚚 Free Shipping Above ₹1,000* & ₹1,500* all over India
🔁 7 Days Easy Return – Shop Stress-free

* Free Shipping- North Zone Above ₹1,000 and Rest Of India ₹1,500

Description

The 1L-MSO-102L Overhead Mount Reed Switch works by the use of a magnetic field to trip its internal normally open reed contacts. Paired with a compatible magnet and correctly aligned within its defined operating gap, the switch provides consistent and reliable switching for control and signalling circuits.This switch is not designed for compact electronic devices or consumer products but rather made for industrial, automation, and access-monitoring use in which the mechanical positioning and magnetic sensing should remain the same under repeated operation.It is manufactured under strict quality standards, making this model perfect for installations where space barriers are medium but reliability and mechanical stability are important.Beyond industrial roller shutters, the 1L-MSO-102L Overhead Mount Reed Switch also performs reliably in commercial overhead door applications, warehouse shutter monitoring, and professional-grade security alarm systems. As a result, a single SKU covers multiple project requirements, reducing procurement complexity for B2B buyers.

Key Features

1/4″ Press Fit Mini Switch
Operating Gap 1/2″ (12 mm) min
18″ long wire Leads

Application Suitability of 1L-MSO-102L

The 1L-MSO-102L Overhead Mount Magnetic Switch must be used in applications where the mounting style, operating gap and electrical characteristics of this switch are suitable. Typical applications include:

Industrial doors and shutters
Electrical compound and panels
Guarding of machines and covering safety
Automation equipment position sensing
Access control and monitoring systems
Various interlock mechanisms on safety
